VW Amarok Towing Capacity

VW Amarok Towing Capacity: A Workhorse for Every Job

When it comes to heavy-duty vehicles, the VW Amarok stands out as a powerhouse. Its impressive towing capacity has made it a favorite among those who need a reliable workhorse for demanding jobs. The VW Amarok towing capacity is a key feature that sets it apart from other pickup trucks in its class, offering the strength and versatility to handle a wide range of towing tasks. Source

This article delves into the specifics of the VW Amarok’s towing capabilities, exploring different models and their respective capacities. We’ll also look at important factors like payload, weight, and dimensions that affect towing performance. Additionally, we’ll examine the Amarok’s towing features, including its heavy-duty tow bar and bed options like the sliding bed tray and load liner. Whether you’re considering a single cab or double cab Amarok, you’ll find valuable insights to help you make an informed decision about this robust pickup truck.

Understanding VW Amarok’s Towing Capacity

The VW Amarok has established itself as a formidable player in the pickup truck market, largely due to its impressive towing capacity. This section delves into the specifics of the Amarok’s towing capabilities, exploring the maximum limits and factors that influence its performance. See all VW Amarok lease deals

Maximum Towing Capacity VW Amarok Towing Capacity

The VW Amarok boasts a substantial towing capacity that sets it apart from many competitors in its class. The standard towing capacity of the Amarok is 3100kg. However, with certain modifications, this capacity can be increased to an impressive 3500kg. This enhancement is achieved through the use of a normal hitch and is possible on a standard B + E license, which allows for towing up to 3500kg plus a trailer. See New VW Amarok

For those requiring even more towing power, the Amarok offers an option to uprate the vehicle to a 6400kg Gross Train Weight (GTW). This upgrade involves the installation of a rear semi-air suspension kit and an application to the DVLA for a new chassis plate. This 6400kg conversion is available for all 2.0 TDI and 3.0 TDI Amarok models, both manual and automatic transmissions. See VW Amarok colours

Braked vs. Unbraked Towing

When considering the Amarok’s towing capacity, it’s crucial to understand the distinction between braked and unbraked towing: See VW Amarok 2024

Braked Towing: The Amarok’s maximum braked towing capacity is 3500kg. This refers to trailers equipped with their own braking system, allowing for heavier loads to be towed safely.
Unbraked Towing: For trailers without brakes, the maximum towing capacity is limited to 750kg. This is a standard limit for most vehicles, ensuring safety when towing lighter loads. See VW Amarok 2023

It’s important to note that these figures can vary depending on the specific model and configuration of the Amarok. Always consult the manufacturer’s guidelines or the owner’s manual for the exact specifications of your particular vehicle. See VW Amarok 2025

Factors Affecting VW Amarok Towing Capacity

Several factors influence the Amarok’s towing capacity and overall performance:

Payload and Gross Vehicle Weight Rating (GVWR): The Amarok’s payload capacity increases significantly with the 6400kg upgrade. At full tow capacity, the payload can reach up to 600kg, which is a substantial improvement over many competitors that still operate under a 6000kg limit. See VW Amarok Alloy wheels
Towbar Specifications: The towbar itself plays a crucial role in determining the maximum towing capacity. The factory setup typically has a D-Value of 16.4kN. However, to legally tow 3.5 tons with a vehicle weighing 3.5 tons, a minimum D-Value of 17.2kN is recommended.
Tire Ratings: The upgraded 2200kg rear axle weight is slightly higher than the standard load rating of factory-fitted tires. To accommodate this, owners may need to consider upgrading to tires with a higher load rating, such as 112 or above.
Gross Combination Mass (GCM): This is the total allowable weight of the vehicle and trailer combined. For the Amarok, this can be up to 6400kg with the appropriate upgrades.
Vehicle Configuration: The towing capacity can vary depending on whether the Amarok is a single cab or double cab model, as well as the specific engine and transmission combination.

Understanding these factors is essential for Amarok owners to maximize their vehicle’s towing potential while ensuring safe and legal operation. It’s always recommended to consult with VW specialists or refer to the vehicle’s manual for precise towing specifications and guidelines.

VW Amarok Models and Their Towing Capabilities

The Volkswagen Amarok has established itself as a formidable player in the pickup truck market, offering impressive towing capabilities across its various models. The towing capacity of the Amarok has evolved over the years, with recent models boasting substantial improvements in their ability to handle heavy loads.

V6 Diesel Models

The V6 diesel engine models of the Amarok stand out for their exceptional towing performance. These powerhouses come equipped with a 3.0-liter diesel engine that delivers 258PS through an 8-speed automatic gearbox. This combination results in remarkable acceleration, with the ability to reach 0-60mph in just 7.4 seconds, even when towing.

The V6 models demonstrate impressive fuel efficiency, delivering around 33mpg combined. When towing on long runs, owners can expect between 20-26 mpg, which is commendable considering the vehicle’s power and capabilities. The VW 4Motion system, standard on these models, provides four-wheel drive functionality, enhancing stability and control while towing. This feature ensures that the front of the vehicle never feels light, even with a heavy load attached.

4-Cylinder Models VW Amarok Towing Capacity

While the V6 models offer top-tier performance, the 4-cylinder Amarok variants also provide robust towing capabilities. These models have seen improvements in their towing capacity over the years. For instance, earlier models from 2011 had a braked towing capacity of 2800kg, which increased to 3000kg from 2012 onwards.

The 4-cylinder models, particularly those with the 2.0-liter engine, offer a balance between power and efficiency. While they may not match the V6 in terms of raw power, they still provide adequate performance for most towing needs. However, when towing heavier loads, some users have reported that the 2.0-liter models might experience more strain compared to their V6 counterparts.

Automatic vs. Manual Transmission

The choice between automatic and manual transmission can significantly impact the Amarok’s towing experience. The 8-speed automatic transmission, available in newer models, has garnered praise for its smooth operation and efficient power delivery when towing.

Automatic Transmission:
- Offers smoother pull-aways, especially on steep inclines
- Reduces strain on the drivetrain during heavy towing
- Provides better control and ease of use in various towing situations
Manual Transmission:
- May require more skill and effort when towing, especially on inclines
- Can experience clutch wear with frequent heavy towing
- Offers more direct control for experienced drivers

Many Amarok owners who frequently tow trailers or caravans prefer the automatic transmission for its ease of use and reduced wear on the vehicle. The torque converter in the automatic models helps with smooth pull-aways and reduces strain on the system during heavy towing.

It’s worth noting that the towing capacity of the Amarok has increased over the years. Recent models (2022-2024) boast a braked towing capacity of up to 3500kg, a significant improvement from the earlier models. However, it’s crucial to remember that in some regions, such as South Africa, legal restrictions may limit the maximum towing weight to the vehicle’s tare weight, which is around 1980kg for double cab Amaroks.

When considering an Amarok for towing purposes, it’s essential to factor in the specific model year, engine type, and transmission. While the V6 models offer superior performance, the 4-cylinder variants still provide capable towing abilities for most everyday needs. Ultimately, the choice between models should be based on individual towing requirements, budget considerations, and personal preferences regarding power and fuel efficiency.

Payload and Gross Vehicle Weight Rating

Payload Capacity

The VW Amarok’s payload capacity is a crucial factor for potential buyers, especially those intending to use the vehicle for commercial purposes. The payload capacity varies across different versions of the Amarok, making it essential for buyers to carefully consider their specific needs.

Most Amarok models offer a payload capacity exceeding 1,000kg, which qualifies them for commercial vehicle taxation benefits. However, some versions, particularly those with higher trim levels, have lower payload capacities. For instance, the Aventura trim, despite its luxurious features, has a compromised gross vehicle weight, resulting in a payload below the 1,000kg threshold. This reduction has significant implications for taxation and overall costs.

The payload capacities for different Amarok trims and configurations are as follows:

Trim Level	Engine	Transmission	Payload
Trendline	2.0L	Manual	1,146kg
Life	TDI500	Automatic	929kg
Style	V6	Automatic	972kg
Aventura	3.0L V6	10-speed auto	877kg
Aventura (with Towing Pack)	3.0L V6	10-speed auto	842kg

It’s worth noting that the Aventura trim, especially with the Towing Pack, falls significantly below the 1,000kg mark. This reduction in payload capacity can lead to additional costs in VAT and Benefit in Kind (BIK) rates.

GVWR Explained

The Gross Vehicle Weight Rating (GVWR) is a critical specification that determines the maximum allowable weight of the vehicle, including its cargo and passengers. For the Amarok, the GVWR has a direct impact on its payload capacity and overall versatility.

Volkswagen has implemented changes to how it calculates the Amarok’s payload. Previously, it was calculated as GVWR minus tare weight (with 10 liters of fuel). Now, it’s calculated as GVWR minus kerb weight (with a full tank of fuel), aligning with industry standards. This change has resulted in slightly reduced payload figures on paper, but it provides a more accurate representation of real-world capabilities.

The Amarok’s GVWR varies depending on the model and configuration. For instance, some V6 variants have a Gross Combination Mass (GCM) of up to 6,400kg, which is higher than many competitors capped at 6,000kg. This increased GCM allows for greater flexibility when balancing payload and towing capacity.

Balancing Payload and Towing

One of the challenges Amarok owners face is balancing payload and towing capacity within the vehicle’s GVWR and GCM limits. While the Amarok boasts impressive towing capabilities, it’s crucial to understand that maximum payload and maximum towing capacity cannot be achieved simultaneously.

For example, when towing at the maximum capacity of 3,500kg, the available payload for the vehicle itself is significantly reduced. This limitation is common among pickup trucks but is particularly noticeable in the Amarok due to its high towing capacity.

To address this, Volkswagen offers options to increase the vehicle’s capabilities:

Uprating to 6,400kg GCM: This upgrade involves installing a rear semi-air suspension kit and obtaining a new chassis plate from the DVLA. The cost ranges from £1,500 to £2,300 plus VAT, depending on the suspension specification chosen.
Increased Rear Axle Weight: The upgrade allows for a 2,200kg rear axle weight, which is 20kg more than the standard tire load rating. Owners may need to consider upgrading to tires with a higher load rating (112 or above) to accommodate this increase safely.
Towbar Considerations: For legal and safe towing at maximum capacity, a towbar with a D-Value of at least 17.2kN is recommended, higher than the standard 16.4kN.

These upgrades can significantly enhance the Amarok’s versatility, allowing for a payload increase of up to 600kg when towing at full capacity. This capability sets the Amarok apart from many competitors that still operate under a 6,000kg GCM limit.

Towing Features and Technologies

The Volkswagen Amarok comes equipped with a range of advanced features and technologies designed to enhance its towing capabilities and ensure a safe, stable towing experience. These innovations address common challenges associated with towing heavy loads and provide drivers with greater control and confidence on the road.

Trailer Sway Control VW Amarok Towing Capacity

One of the standout features of the Amarok is its Trailer Stabilization system, also known as trailer sway control. This technology plays a crucial role in reducing the risk of jack-knifing and tipping over while towing. The system works by gently controlling the braking and reducing engine torque when it detects trailer sway. This feature is particularly beneficial given the Amarok’s impressive towing capacity and its substantial kerb weight of 2.2 tons, which already contributes to improved stability.

It’s worth noting that the Amarok’s trailer stability control is not a function of the towbar itself. Instead, it relies on the connection between the vehicle’s ECU and the trailer through the electrical loom. This integration allows for seamless communication between the truck and the trailer, enabling quick response to any detected instability.

Hill Descent Control VW Amarok Towing Capacity

The Amarok’s hill descent control is another valuable feature for towing enthusiasts. This system provides a controlled and comfortable downhill descent at a constant speed. It remains active up to 36 km/h and passive up to 68 km/h. Drivers can control the speed using the Adaptive Cruise Control buttons on the steering wheel, allowing for precise management of descent speed when towing on steep inclines.

Additionally, the Amarok offers assistance for starting on inclines. The vehicle automatically detects when it’s at a standstill on an incline and holds the position for 2-3 seconds after the driver releases the brake. This feature provides a smooth and controlled start, particularly useful when towing heavy loads uphill.

Towing Assist Systems

The Amarok boasts several towing assist systems that significantly improve the overall towing experience:

Trailer Hitch Camera: This aerial view camera provides an overhead view of the towbar, making it easier for drivers to hitch their trailers accurately.
Trailer Mode: This feature optimizes gearbox operation when towing heavy loads. Drivers can register their trailer’s size in the driver assistance systems, allowing the Amarok to adjust its blind spot sensors and drive assistance to accommodate the additional dimensions at the rear. The system can account for trailers up to 2.5 m wide and 10.1 m long.
Gearbox Optimization: The Amarok’s handbook recommends shifting the gearbox into sport mode for towing. This extends the rev range in each gear before an upshift occurs, providing more power when needed. Drivers also have the option to use manual mode, allowing for precise control over gear shifts.
Automatic Adjustments: When a trailer is connected, the Amarok automatically makes several adjustments. These include disabling the rear parking sensors, modifying the electronic stability system and ABS settings, and adapting off-road and gearbox modes for optimal towing performance.

These features collectively contribute to the Amarok’s reputation as a capable and reliable towing vehicle. They provide drivers with the tools and assistance needed to handle a variety of towing situations with confidence and safety.

Real-World Towing Performance

Customer Experiences

Owners of the Volkswagen Amarok have reported positive experiences when towing heavy loads. One user shared their experience towing a 24ft Jayco Silverline caravan weighing around 3000kg. They noted that the Amarok handled the combined weight of approximately 5500kg well, with both the four-cylinder and V6 models demonstrating impressive performance.

The V6 model, in particular, received praise for its ability to maintain speed and even accelerate up inclines while towing. Users appreciated the Amarok’s stability, with little sway or pitching observed during towing. The vehicle’s width also contributed to a secure feeling, with drivers reporting that they quickly became accustomed to the caravan’s alignment.

One Amarok owner, towing a caravan with a total outfit length of 41 feet 6 inches, shared that after a couple of miles, they hardly noticed the caravan’s presence. They were particularly impressed with the Amarok’s acceleration, noting that it “took off like a scalded cat” when needed, a significant improvement over their previous towing vehicle.

Professional Reviews VW Amarok Towing Capacity

Professional reviews have also highlighted the Amarok’s towing capabilities. In controlled tests, the Amarok demonstrated impressive stability, especially in still air conditions. At highway speeds, only slight sway was observed, and even in stiff breezes, the vehicle maintained its composure.

The Amarok’s braking performance while towing has been particularly noteworthy. In one test, it achieved a stopping distance of 10.8m from 30mph while towing, outperforming many luxury 4x4s in similar conditions. This addresses a common concern with pickup trucks, as braking has often been a weak point in towing situations.

The V6 engine’s power has been consistently praised in reviews. Even when towing heavy caravans, the engine’s performance remains strong, with reviewers noting its ability to maintain speed on inclines and accelerate when needed.

Towing Efficiency and Fuel Consumption

When it comes to efficiency and fuel consumption while towing, the Amarok has shown promising results. During towing tests, the engine temperature remained stable at 90 degrees, with oil temperature varying between 85 and 99 degrees, indicating that the engine wasn’t under excessive strain.

The 10-speed transmission has been noted to keep both the four-cylinder and V6 engines in their optimal power range, with peak torque available from 1750rpm. This efficient power delivery contributes to the Amarok’s towing performance and fuel economy.

However, it’s important to note that towing does impact fuel consumption. While specific figures weren’t provided in the available information, users should expect increased fuel usage when towing heavy loads. The Amarok’s engine revs typically increase from around 1500rpm without a trailer to about 2000rpm when towing, which will naturally lead to higher fuel consumption.

In conclusion, real-world experiences and professional reviews consistently highlight the Volkswagen Amarok’s strong towing performance. Its stability, power, and braking capabilities make it a reliable choice for those needing to tow heavy loads regularly. While fuel efficiency will inevitably decrease when towing, the Amarok’s efficient powertrain helps mitigate this to some extent.

Conclusion VW Amarok Towing Capacity

The Volkswagen Amarok has proven itself as a formidable player in the pickup truck market, with its impressive towing capacity and advanced features. Its ability to handle heavy loads, coupled with technologies like trailer sway control and hill descent assist, makes it a top choice for those needing a reliable workhorse. The Amarok’s real-world performance, as seen in customer experiences and professional reviews, further cements its reputation as a capable towing vehicle.

For those in the market for a pickup that can handle demanding towing tasks, the Amarok stands out as a strong contender. Its range of models, from the efficient four-cylinder options to the powerful V6 variants, offers flexibility to suit various needs and preferences. While fuel consumption increases when towing, the Amarok’s efficient powertrain helps to minimize this impact, making it a practical choice for both work and leisure towing requirements.

FAQs

Can the towing capacity of a VW Amarok be increased?
Yes, it is possible to enhance the towing capacity of the VW Amarok. By upgrading, the gross towing weight can be increased to 6400GTW, and the towing capacity can be elevated from the standard 3.1 tons to 3.5 tons using a normal hitch. This upgrade is permissible under a Normal License – B + E (3500kg + Trailer).

Why is towing capacity important?
Towing capacity is crucial as it determines the maximum weight your vehicle can safely tow. Exceeding this limit can overburden the vehicle’s powertrain and may compromise braking ability, risking both safety and vehicle integrity.

Is the VW Amarok suitable for towing?
Yes, the VW Amarok is well-suited for towing, with a capacity to tow up to 3500kg, making it a strong choice for various towing needs.

What is the payload capacity of the VW Amarok?
The latest VW Amarok can handle a significant payload of up to 1.13 tons, in addition to having a towing capacity of 3.5 tons. It also boasts advanced drive, assist, and control systems, along with a cargo box designed for enhanced utility.
