Ford Transit Custom LWB

A long-wheelbase medium van built for enhanced load capacity and dependable business use

The Ford Transit Custom LWB has become a game-changer in the commercial vehicle market, offering a perfect blend of functionality and versatility. This long wheelbase variant of the popular Ford Transit Custom van has caught the attention of businesses and individuals alike, thanks to its impressive dimensions and load-carrying capabilities. With its extended body length and increased cargo capacity, the Ford Transit Custom LWB is designed to meet the demands of various industries, from construction to delivery services. Source

This comprehensive review delves into the key aspects of the Ford Transit Custom LWB, exploring its performance, efficiency, and cargo capacity. We'll take a closer look at its dimensions, including the Ford Transit Custom LWB high roof option, and compare it to the standard wheelbase model. Additionally, we'll examine the available accessories, racking options, and the Ford Transit Custom Trail variant. By the end of this article, readers will have a clear understanding of the Ford Transit Custom LWB's value proposition and how it stacks up against its competitors in the commercial van segment.

Overview of the Ford Transit Custom LWB

The Ford Transit Custom LWB (Long Wheelbase) is a versatile commercial vehicle that offers enhanced cargo capacity and flexibility compared to its standard counterpart. This variant has a wheelbase of 3,300mm, which is the distance between the centre of the front and rear wheels. The extended wheelbase results in a load length of 2,922mm, which can be further increased to 3,452mm with the load-through bulkhead.

Why the Ford Transit Custom LWB is ideal for UK commercial leasing

The Transit Custom L2 LWB is available in two roof heights: low roof (H1) and high roof (H2). The load bed to roof heights measure 1,406mm for the low roof and 1,778mm for the high roof. The loading height, which is the distance from the floor to the load bed, is 588mm, lowering to 444mm when fully laden.
The side loading doors are 1,030mm wide and 1,324mm high on all models, while the rear doors measure 1,404mm wide and 1,347mm high, extending to 1,706mm on the high roof variant. The load volumes range from 6.2 cubic metres for the long wheelbase, low roof (L2H1) to 7.7 cubic metres for the long wheelbase, high roof (L2H2).

Target market and use cases Ford Transit Custom LWB

The Ford Transit Custom LWB caters to a wide range of customers, from businesses requiring ample cargo space to those planning van life conversions. Its extended length and increased load capacity make it ideal for industries such as construction, delivery services, and mobile workshops. The vehicle's versatility is further enhanced by its availability in various configurations, including panel van, Double Cab-in-Van (DCiV), and Kombi options.

Comparison with standard Transit Custom

Compared to the standard Transit Custom, the LWB variant offers several advantages. The extended wheelbase provides more load space, allowing for the transportation of larger items or a greater volume of cargo. The LWB model also offers a smoother ride due to the increased distance between the wheels, resulting in better handling over bumps and dips in the road. Additionally, the larger size contributes to improved stability and potentially better fuel economy, as drivers tend to adopt a more relaxed driving style in larger vehicles. See all Ford Transit Custom Lease

Performance and Efficiency

Engine options and power output

The Ford Transit Custom LWB offers a range of engine options to suit various needs. The current lineup features a 2.0-litre EcoBlue turbodiesel engine, available in multiple power outputs. These include 105 PS, 130 PS, and 170 PS versions, with the addition of a 185 PS variant in late 2019. The EcoBlue engines provide improved performance and efficiency compared to their predecessors, with increased torque at lower revs for better driveability.

Fuel economy and emissions

Fuel efficiency has seen improvements in the latest Transit Custom models. The most economical diesel variant achieves 40.4 mpg with emissions of 183 g/km. For those seeking even greater efficiency, Ford offers a mild hybrid (PHEV) option on select models, which can improve fuel economy by up to 8% in urban driving conditions. The Transit Custom also features a 21-litre AdBlue tank for exhaust gas treatment, contributing to its Euro 6 emissions compliance.

Driving experience and handling Ford Transit Custom LWB

The Transit Custom LWB impresses with its driving dynamics, offering a more car-like experience than many competitors. Its handling is particularly noteworthy, with excellent cornering abilities and minimal body roll. The van's suspension effectively absorbs bumps, providing a comfortable ride, especially when carrying a load. The steering is responsive and well-calibrated, making the Transit Custom easy to manoeuvre in urban environments. With its tight turning circle and smooth gearbox, this van delivers a refined driving experience that stands out in its class. See Ford E Transit Custom

Cargo Capacity and Versatility

The Ford Transit Custom LWB stands out for its impressive cargo capacity and versatility, making it a top choice for businesses requiring ample space and flexibility. With load volumes ranging from 6.0 cubic metres in the L1H1 (short wheelbase, low roof) to 8.3 cubic metres in the L2H2 (long wheelbase, high roof), this van offers exceptional storage options.

Load space dimensions

The Transit Custom LWB has a load length of 2,922mm, which can be extended to 3,452mm with the load-through bulkhead. This feature allows for the transportation of items up to 3.4 metres in length, such as pipes and ladders. The load bed to roof heights measure 1,406mm for the low roof and 1,778mm for the high roof, providing ample vertical space for cargo.

Payload capacity Ford Transit Custom LWB

The Transit Custom LWB has a payload capacity ranging from 686kg to 1,459kg, depending on the model. The most popular variant, the 320 L1H1 with manual gearbox, offers a payload between 1,170kg and 1,232kg. For those requiring maximum carrying capacity, the Transit Custom 340 L1H1 with manual gearbox has the highest payload in the range.
Ford Transit Custom Double Cab Grey Matter LWB

Customisation options

Ford offers various customisation options to enhance the Transit Custom LWB's versatility. These include ply racking, shelving, and storage solutions. Additionally, aftermarket upgrades such as roof racks, alloy wheels, seat covers, and tow bars are available. The van's design allows for easy loading, with wide-opening rear doors and a pallet-sized sliding door on both driver and passenger sides.

Pricing and Value for Money Ford Transit Custom LWB

The Ford Transit Custom LWB offers competitive pricing and excellent value for money in the medium van segment. When compared to its rivals, the Transit Custom price holds its own in terms of cost-effectiveness and features. See all Ford Transit custom vans for sale.

Cost comparison with competitors

The Ford Transit Custom 340S SWB with a 2.0-litre turbo-diesel engine and six-speed auto has a list price of £44,990. This positions it between the Hyundai iLoad (£42,710) and the Toyota HiAce LWB (£45,240), making it a mid-range option in terms of initial cost.

Standard equipment and optional extras

The Transit Custom comes well-equipped as standard, offering features such as:

• 8.0-inch media screen
• Apple CarPlay, Android Auto, and Bluetooth connectivity
• Cruise control
• Air conditioning
• Keyless entry
• Leather-accented steering wheel
• Driver inboard armrest

These features are comparable to, and in some cases surpass, those offered by competitors. The Transit Custom also offers unique options like the Pro Power Onboard technology, providing up to 2.3kW of power for tools and equipment.

Total cost of ownership analysis

When considering the total cost of ownership, the Transit Custom performs admirably. Its 2.0-litre EcoBlue turbodiesel engines offer low running costs and impressive fuel efficiency. In real-world testing, the Transit Custom achieved a frugal 8.2L/100km, translating to a driving range of around 850km from its 72-litre tank. This efficiency contributes to lower long-term costs for businesses.

Conclusion Ford Transit Custom LWB

The Ford Transit Custom LWB has shown itself to be a versatile and capable commercial vehicle, offering a blend of performance, efficiency, and practicality. Its extended wheelbase and increased cargo capacity make it a strong contender for businesses looking to maximise their transport capabilities. The van's impressive fuel economy, coupled with its range of engine options and customization possibilities, gives it an edge in the competitive commercial vehicle market.
To wrap up, the Transit Custom LWB's combination of driving comfort, ample cargo space, and competitive pricing makes it a top choice for a wide range of industries. Its ability to adapt to various needs, from construction to delivery services, highlights its versatility. As Ford continues to innovate in this segment, the Transit Custom LWB is likely to remain a key player, meeting the evolving demands of businesses and individuals alike.

FAQs Ford Transit Custom LWB

What typical problems can occur with the Ford Transit Custom?
The Ford Transit Custom may experience several common issues, including difficulties with the clutch and gearbox, electrical problems, complications with the diesel particulate philtre, turbocharger issues, concerns with the cooling system, suspension glitches, brake problems, and troubles with the Exhaust Gas Recirculation (EGR) valve.
How dependable is the Ford Transit Custom?
Generally, the Ford Transit Custom is considered reliable. However, there are occasional problems with cambelt failure in models with "wet belt" engines. It's important to note that these belts can sometimes fail before reaching Ford's recommended replacement interval of seven years or 144,000 miles.
Which Ford Transit Custom model is the best to purchase?
The choice of the best Ford Transit Custom depends on your specific requirements. However, the 2.0 136 EcoBlue engine is highly recommended due to its superior payload and towing capacities within the range.
What are the drawbacks of the Ford Transit?
Some older Ford Transit models may exhibit issues such as transmission failure, electrical faults, suspension problems, and unreliable brakes. There have also been some complaints regarding difficulties with the rear door. However, these problems are significantly rarer in the more recent models of the Ford Transit.
